Maxell's Adhesive Tapes for construction and civil engineering are utilized in everywhere for developing of new town from skyscraper to individual housing.

Recent construction and civil engineering fields have used adhesive tapes at any scene from high Mega-Mall, high rise building to individual housing by affecting of construction technology development. At the same time, adhesive tapes are indispensable for further effective and simple construction operation, lower cost performance and environmental provisions.

Construction and civil engineering
Large Suspension Bridges

Large Suspension Bridges

Filament reinforced tape having excellent crush resistance and durability is used for the main cables of long-span suspension bridges. The tape is also excellent for bonding various wire rods, laminate coils, and terminal stops of trans-coils.

Stadiums

Stadiums

Butyl tape has excellent adhesive properties for waterproofing concrete joints in the stands of outdoor athletic facilities such as sports arenas used for international events, ballparks, and soccer stadiums.

Factories

Factories

Butyl tape is optimized for diverse applications, for example, as a sealing material for seam joints of metal roofs in factory facilities and as an airtight sealing material for piping in a refrigerated warehouse. It can maintain well-balanced, high-adhesive strength over a wide temperature range for a long time.

Construction Sites

Construction Sites

At construction sites, the attention of passers-by can be attracted using adhesive tapes for displaying various markings indicating danger and prohibitions, warning labels, and safety signs. The tape has excellent manual cutting performance, yet adheres well to rough surfaces such as concrete or plywood.

Buildings and Apartments

Buildings and Apartments

The tape exhibits excellent moisture-proof properties, aeration resistance, weather resistance, and anti-aging performance for sealing duct joints and heat-insulating joints, as well as in rooftop water stop and waterproofing work. We also provide a broad array of support for construction works in housing complexes, offices, and tenant buildings with curing tapes for curing iron frames, reinforcing bars, and iron tubes on roofs and on concrete surfaces exposed to harsh environments, as well as to prevent dust from scattering during indoor works.

Town City
Single Family Home

Single Family Home (Masking)

The tape is used for a wide range of applications such as protecting floor surfaces in two-by-four housing construction, fixing curing sheets during interior finishing work, refurbishment, and moving work.

Single Family Home

Single Family Home (Renovation)

Butyl tape has excellent adhesive properties for waterproofing concrete joints in the stands of outdoor athletic facilities such as sports arenas used for international events, ballparks, and soccer stadiums.

Single Family Home

Single Family Home (Waterproofing/Air-tightening)

Butyl tape is mainly used for waterproofing and preventing drafts around sashes. The tape demonstrates high adhesion to any adherend and durability. In addition, it remains pliable even at low temperatures and settles well in complicated parts. Because it also has superb sound insulation and vibration control properties, the tape can be used in a wide range of applications.

Public Facilities

Public Facilities (Waterproofing)

Butyl tape with excellent waterproof and air-tight properties is used as a water stop seal for joint ducts of lifelines in large-scale public facilities such as universities, general hospitals, and convention centers.

Product List

This is a list of typical uses and the products suitable for them.

In addition to this, we have a variety of other products available.

Large Suspension Bridges / Binding (Main cables)

ModelApplicationFeaturesTape thicknessAdhesion
No.9110
No.9110
For bundling, For fixing the end of steel sheet coils High tensile strength, Tensile strength: 696N/10mm 0.19mm 3.90N/10mm
No.9510
No.9510
For temporary fixing of home appliances or furniture Anti-staining property, Available color: 4 colors, Tensile strength: 320N/10mm 0.17mm 4.65N/10mm

Stadiums / Waterproofing (Stands)

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.9244
No.9244
For waterproofing of houses Excellent durability and water resistance 0.50mm 9.81N/10mm

Buildings and Apartments / Joint insulation

ModelApplicationFeaturesTape thicknessAdhesion
No.8060
No.8060
For air-conditioning duct seals, and jont sealing of heat insulation material Application temperature: -30∼130degrees C 0.105mm 4.80N/10mm
No.9810
No.9810
For air conditioning duct sealing, For joint sealing of heat insulation material Application temperature: -20∼130degrees C, Good adhesion under low temperatures 0.195mm 4.00N/10mm

Buildings and Apartments / Waterproofing (Roof)

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.9244
No.9244
For waterproofing of houses Excellent durability and water resistance 0.50mm 9.81N/10mm

Buildings and Apartments / Masking (Painting)

ModelApplicationFeaturesTape thicknessAdhesion
No.3372
No.3372
Outdoor masking 55 mesh, Limited residue, Polyethylene laminated cloth, Ppreventing UV ray penetration, Easy unrolling, Easy tear, Made in Indonesia/Japan, Some color variation 0.29mm 2.80N/10mm
No.3430
No.3430
Long term outdoor masking 80 mesh, Premium grade, Limited residue, Strong backing, Superior weather resistance, Easy unrolling, Easy tear, Silver, Light grey, Made in Indonesia/Japan 0.33mm 2.94N/10mm

Factories / Waterproofing (Folded plate roof)

ModelApplicationFeaturesTape thicknessAdhesion
No.5931
No.5931
For waterproofing and temporary fixing of exterior walls Excellent durability and water resistance, 1mm thickness 1.00mm 1st surface: 9.80N/10mm, 2nd surface: 9.80N/10mm

Factories / Waterproofing (Refrigerated warehouse)

ModelApplicationFeaturesTape thicknessAdhesion
No.9290
No.9290
For waterproofing of houses, For air-tightening and waterproofing of factories Water vapor permeability: 0.5g/m²·24h 0.50mm 7.84N/10mm
No.9830
No.9830
For waterproofing of joints, For surface protection Water vapor permeability: 0.5g/m²·24h 0.60mm 11.76N/10mm

Construction sites / Danger indicators, Reflective

ModelApplicationFeaturesTape thicknessAdhesion
No.9652
No.9652
For hazard warning displays on construction sites, in factories, at stations, etc High reflectivity, Available color: 1 color 0.115mm 3.88N/10mm

Single Family Home (Masking) / Floor masking, Moving

ModelApplicationFeaturesTape thicknessAdhesion
No.3448
No.3448
Fixing of masking sheet at interior work and renovation Standard Type, Acrylic adhesive, Easy unrolling, Easy tear, Protec Tape, 2 colors(Green/Natural), Plastic core available 0.15mm 3.60N/10mm
No.3490
No.3490
Fixing of masking sheet at interior work and renovation Acrylic adhesive, Good manual tearability, Good workability, Easy unrolling, Easy tear, Four colors 0.11mm 2.50N/10mm

Single Family Home (Renovation) / Kitchen panels

ModelApplicationFeaturesTape thicknessAdhesion
No.5567
No.5567
For temporary fixing by co-using with glue until curing of glue for interior finishing materials Following property to uneven surface, Good initial adhesion 1.100mm 1st surface: 4.50N/10mm, 2nd surface: 4.50N/10mm

Single Family Home (Renovation) / Floor heating

ModelApplicationFeaturesTape thicknessAdhesion
No.8071
No.8071
For fixing of heat releasing pipe of refrigerators, etc Application temperature: 0∼100degrees C, No release liner 0.080mm 4.00N/10mm
No.8073
No.8073
For fixing of heat releasing pipe of refrigerators, etc Application temperature: 0∼100degrees C, No release liner 0.100mm 4.80N/10mm

Single Family Home (Waterproofing/Air-tightening) / Sash board corners

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.9244
No.9244
For waterproofing of houses Excellent durability and water resistance 0.50mm 9.81N/10mm

Single Family Home (Waterproofing/Air-tightening) / Waterproofing (around sashes)

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.5938
No.5938
Frame building . waterproofing and patching Excellent durability and water resistance, 0.5mm thickness 0.50mm 1st surface: 7.84N/10mm, 2nd surface: 7.84N/10mm

Single Family Home (Waterproofing/Air-tightening) / Fixing of waterproofing sheets

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.9244
No.9244
For waterproofing of houses Excellent durability and water resistance 0.50mm 9.81N/10mm

Single Family Home (Waterproofing/Air-tightening) / Waterproofing (solar panel mount)

ModelApplicationFeaturesTape thicknessAdhesion
No.5931
No.5931
For waterproofing and temporary fixing of exterior walls Excellent durability and water resistance, 1mm thickness 1.00mm 1st surface: 9.80N/10mm, 2nd surface: 9.80N/10mm
No.5938
No.5938
Frame building . waterproofing and patching Excellent durability and water resistance, 0.5mm thickness 0.50mm 1st surface: 7.84N/10mm, 2nd surface: 7.84N/10mm

Public Facilitites (Waterproofing) / Lifeline public utility conduit

ModelApplicationFeaturesTape thicknessAdhesion
No.4420
No.4420
Frame building waterproofing and patching EExcellent durability and water resistance 0.75mm 7.84N/10mm
No.9244
No.9244
For waterproofing of houses Excellent durability and water resistance 0.50mm 9.81N/10mm
